Description
Dell UD22 USB Type C Docking Station for Notebook/Monitor - 130 W - 3 Displays Supported - 5K, 4K - 5120 x 2880, 3840 x 2160 - USB Type-A - 2 x USB Type-C Ports - USB Type-C - 1 x RJ-45 Ports - Network (RJ-45) - 1 x HDMI Ports - HDMI - 2 x DisplayPorts - DisplayPort - Wired - Gigabit Ethernet - Windows, macOS, Chrome OS
Tech Specs
General
Product Type
Docking stationWidth
7.6 cmDepth
16.6 cmHeight
3.2 cmWeight
416 gVideo
Max Resolution Details
5K - 60 HzNetworking
Data Link Protocol
Gigabit EthernetExpansion / Connectivity
Interfaces
- 2 x display / video - DisplayPort - 20 pin DisplayPort (1.2)
- 1 x display / video - HDMI
- 1 x USB-C 3.2 Gen 2/DisplayPort
- 1 x USB 3.2 Gen 2 with PowerShare
- 3 x USB 3.2 Gen 2
- 1 x USB-C 3.2 Gen 2
- 1 x network - RJ-45
Miscellaneous
Cables Included
1 x USB-C cable - 0.8 mFeatures
Security lock slot (cable lock sold separately), wake on LAN, 3 LED indicators, MAC address pass-through, wireless vPro, 96W power delivery, High Bit Rate 3 (HBR3), High Bit Rate 2 (HBR2), Kernel Direct Memory Access (DMA) protectionSecurity Slot Type
Kensington nano security slot / Kensington security slotPower
Power Device
Power adapterPower Adapter Wattage
130 WattSystem Requirements
OS Required
Windows 10, Windows 11, Ubuntu 20.04 or later, Apple macOS 12.21 or later, Google Chrome OS 100 or laterManufacturer Warranty
Bundled Services
3 years Advanced Exchange Service and Limited Hardware Warranty
Connectivity Options
Front View
1. USB-A 3.2 Gen 2
2. USB-A 3.2 Gen 2 with PowerShare
3. USB-C 3.2 Gen 2 with PowerShare
1. USB-A 3.2 Gen 2
2. USB-A 3.2 Gen 2 with PowerShare
3. USB-C 3.2 Gen 2 with PowerShare
Rear View
4. Power In
5. HDMI 2.0
6. DisplayPort 1.2 (2)
7. Gigabit Ethernet RJ45
8. USB-A 3.2 Gen 2 (2)
9. USB 3.2 Gen2 Type-C with DisplayPort 1.4 Alt Mode
4. Power In
5. HDMI 2.0
6. DisplayPort 1.2 (2)
7. Gigabit Ethernet RJ45
8. USB-A 3.2 Gen 2 (2)
9. USB 3.2 Gen2 Type-C with DisplayPort 1.4 Alt Mode
